Complete Architectural Design, which include
2D Floor Plan
3D Elevation
Structural & Working Drawings
Electrical, Plumbing & Drainage drawings

Excavation - Upto Yellow soil/Murrum
Plinth ht - 18-24 inches
Ceiling ht - 10ft 6 inches (clear ht)
Lintel ht - 7-8 ft (as per need)
Column Details - As per drawing
Beam Details - As per drawing
Slab Details - As per drawing
Steel - Fe 550
Cement - Jk Super or equivalent
Aggregate - Black(10-20 mm )High density
Sand - Nemawar/Hosangabad
Bricks - Red brick/Fly Ash (Bhatta)
Masonry - As per drawing (Below plinth fly Ash, above plinth red brick)
Elevation - Glass/Wood/Stone/CNC not included

Isolated/pile/Box footing

UGWT-6000-7000 litre (4" Brick +4" RCC)

Architectural Design, which include
2D Floor Plan
3D Elevation
Structural & Working Drawings
Electrical, Plumbing & Drainage drawings

Steel - Jalna
ISI Thermax FE550 (Steel Used 2.5 Kg per 1 sq.ft)
Cement - JK Super or Equivalent PPC Cement
Brick - Red brick/Fly Ash (Refined Bhatta)
Sand - Nemawar/Hoshangabad
Coarse Aggregate(Gitti) - As per Availability Black/10mm 20mm mix aggregate
Column details - As per Structural Drawings Pile/Isometric/Box footing
Beam details As per Architectural/Structural Drawings
Slab details As per Architectural/Structural Drawings
Masonry external walls - As per Architectural Drawings
Internal walls - 4 Woll
Parapet wall - 4 thick wall (upto-3 ft ht)
Elevation - Front elevation Plaster and colour work is included along with glass work as per Architectural Drawings
Slab height - clear ht 10'6" lower floor slab top to upper floor slab bottom
Lintel height - 7'4"
Half cut ring beam above 7ft, in all 4" brick wall
Concrete Strength - Grade of Concrete M20 (1:1.5:3) (Cement: Sand Aggregate)

Living room, Dinning and kitchen - Vitrified Tiles Double charge) tile size of 2'X 2 or 2'x4' (ranges upto 40/-sq ft) if needed grouting will be done inclusive of it
Kitchen dado - vitrified/ceramic tile upto 2 ft above kitchen platform range upto 280/ box. Epoxy grouting included in it
Bedroom, Guestroom and internal lobby space - Vitrified Tiles Range upto 35/-sq ft. Epoxy grouting included in it
Washroom and utility floor - Anti skid tile range upto 280/ box Epoxy grouting included in it
Washroom, utility (Dado tiles) - Ceramic/vitrified tile upto 3ft ht (Above 3ft, it will be charged extral), range upto 350/ box
Balcony, veranda, porch etc - Anti skid tiles range upto 350/ box Epoxy grouting included in it
Stairs - Granite/Stone upto - 90/ sq ft. (including molding & polishing)
Kitchen counter Top - Granite/Stone range upto 140/-sq ft (12'* 2'3" length*Width) including side support - length 12' includes sink
Terrace Finish Brick bat coba on chargeable basis extra

Main door (typical 4'0" * 7'0") (Thick-35 mm) - Frame Sai wood (2.5" * 5") /Granite lamming Hardware in SS finish aluminium upto -20,000/- per door including installation and hardware changes Hardware: (ISI marked ) - Shutter-laminate finish/mica finish outside - 1 no. 8"-9" SS handle, 1 no. SS aldrop, 4no. SS Hinges, Night latch inside - 1 no. 6" SS handle, 1 no. 6" SS tower bolt, 1no. eye piece & L shape door stopper
Internal doors (typical size 3'0" * 7'0") (Thick - 30mm) - Frame Sal wood (2.5"x5") / ply pocketing Hardware in SS finish aluminum upto - 10,000/- per door including installation and hardware charges Hardware: (ISI marked ) - Shutter-laminate finish/mica finish outside - 1 no. aldrop, 3 no. SS Hinges Inside - 1 no. aldrop, 1 no. 6" SS tower bolt, 1 no. Cylinder lock and L shape door stopper
Bathroom doors (typical size 2'6" * 7'0") (Thick-30 mm) Frame Granite Jamming - Hardware in SS finish aluminum upto - 6,000/ per door including installation and hardware charges shutter Fiber/Flush door or equivalent - outside = 1 no. aldrop, 3 no. SS Hinga, Inside = 1 no. aldrop, 1 Taadi
Windows - High Quality Aluminium window 3 track 280/-sq-ft Granite Jamming cost inclusive of it

Plumbing pipe - ISI or Equivalent UPVC & CPVC-grade 135 (cpvc-1/2" (hot water) upvc (3/4" and 1" for cold water)
Drainage Pipe - ISI or Equivalent PVC (SWR-3" and 4") below plinth 6° for single line
Sanitary ware ISI or Equivalent - 1. no. health faucet, 1 no. diverter 1 no. shower 1 no. w/c tap.1 wash basin (Master Bedroom toilet-25,000/-)
ISI or Equivalent - 1. no. health faucet, 1 no. Mixer 1 no. shower 1 no. w/c tap.1 wash basin (Guest Bedroom -20,000/-)
ISI or Equivalent - 1. no. health faucet, 1 no. Mixer 1 no. shower 1 no. w/c tap.1 wash basin (C Toilet - 15,000/-)
Kitchen Sink - Stainless steel grade 304 SS sink upto - 2200/-
OWHT - Supremo/Plasto or equivalent 1000 litre - 4 layer
UGWT - (8" brick ) 6000-7000 litre capacity
Chamber (Size 2'0" * 2'0") Chamber Cover: By kota stone

Internal Putty
Two coat-Birla white/Jk+ primer one coat
Colour emulsion series
External Front elevation Apex Ultima 7 yrs warranty
Other side elevation 2 coat primer
Fabrication Red Oxide Coating and Oil Paint

Window Grill - Bright bar (10mm/12mm) round/square bright bar
Main gate parking - Ms. iron upto 100 kg Ms door (cnc cutting and shera wood panels will be charged extra)
Railing - S.S./MS with Rs.600 per running ft upto ht of 3ft
Head room gate - M.S iron 18 gauge MS. sheet door, upto tili 40 kg
Tower ladder Ms pipe with ladder

Complete Architectural Design, which include
2D Floor Plan
3D Elevation
Structural & Working Drawings
Electrical, Plumbing & Drainage drawings

Steel - Moira ISI Thermax FE550 (Steel Used 2.5 Kg per 1 sq.ft)
Cement - Ultra tech, JK Super PPC Cement
Brick - Red brick/Fly Ash (Refined Bhatta) Available one upto 9 Rs. Per Piece
Sand - Nemawar/Hoshangabad River sand (Rs.60.cu.feet)
Coarse Aggregate(Gitti) - As per Availability Black/10mm 20mm mix aggregate
Column details - As per Structural Drawings Pile/Isometric/Box footing
Beam details As per Architectural/Structural Drawings
Slab details As per Architectural/Structural Drawings
Masonry external walls - As per Architectural Drawings
Internal walls - 4 Woll
Parapet wall - 4 thick wall (upto-3 ft ht)
Below Plinth Fly ash will be used. Above plinth Red brick will be used
Elevation - Front elevation Plaster and colour work is included along with glass work as per Architectural Drawings (Incase other Material used, 10% of Elevation area is inclusive )
Slab height - clear ht 10'6" lower floor slab top to upper floor slab bottom
lintel height - 7'4"
half cut ring beam above 7ft, in all 4" brick wall
Concrete Strength - Grade of Concrete M20 (1:1.5:3) (Cement: Sand Aggregate) 8 bricks per sq ft and 350 cement bag per 1000 sq ft will be used (Above quantity are sufficient enough for sustainable economical building)

Living room, Dinning and kitchen - Vitrified Tiles Double charge) tile size of 2'X 2 or 2'x4' (ranges upto 55/-sq ft) if needed grouting will be done inclusive of it
Kitchen dado - vitrified/ceramic tile upto 2 ft above kitchen platform range upto 350/ box. Epoxy grouting included in it
Bedroom, Guestroom and internal lobby space - Vitrified Tiles Range upto 40/-sq ft. Epoxy grouting included in it
washroom and utility floor - Anti skid tile range upto 350/ box Epoxy grouting included in it
washroom, utility (Dado tiles) - Ceramic/vitrified tile upto 3ft ht (Above 3ft, it will be charged extral), range upto 350/ box
Balcony, veranda, porch etc - Anti skid tiles range upto 350/ box Epoxy grouting included in it
Stairs - Granite/Stone upto - 120/ sq ft. (including molding & polishing)
Kitchen counter Top - Granite/Stone range upto 220/-sq ft (12'* 2'3" length*Width) including side support - length 12' includes sink
Terrace Finish Brick bat coba on chargeable bosis extra

Main door (typical 4'0" * 7'0") (Thick-35 mm) - Frame Sai wood (2.5" * 5") /Granite lamming Hardware in SS finish aluminium upto -30,000/-per door including installation and hardware changes Hardware: (ISI marked ) - Shutter-laminate finish/mica finish outside - 1 no. 8"-9" SS handle, 1 no. SS aldrop, 4no. SS Hinges, Night latch inside - 1 no. 6" SS handle, 1 no. 6" SS tower bolt, 1no. eye piece & L shape door stopper
Internal doors (typical size 3'0" * 7'0") (Thick - 30mm) - Frame Sal wood (2.5"x5") / ply pocketing Hardware in SS finish aluminum upto - 12,000/- per door including installation and hardware charges Hardware: (ISI marked ) - Shutter-laminate finish/mica finish outside - 1 no. aldrop, 3 no. SS Hinges Inside - 1 no. aldrop, 1 no. 6" SS tower bolt, 1 no. Cylinder lock and L shape door stopper
Bathroom doors (typical size 2'6" * 7'0") (Thick-30 mm) Frame Granite Jamming - Hardware in SS finish aluminum upto - 8,000/ per door including installation and hardware charges shutter Fiber/Flush door or equivalent - outside = 1 no. aldrop, 3 no. SS Hinga, Inside = 1. no, aldro, 1 Taadi
Windows - High Quality Aluminium window 3 track 350/-sq-ft Granite Jamming cost inclusive of it Mosquito Door will be charged extra 8000/- per door if required (Rate are inclusive of all taxes) Maximum possible area 300 Sq Ft. per 1000 Sq Ft. (Area For door & window both)

Plumbing pipe - Astral/Supreme or equivalent UPVC & CPVC-grade 135 (cpvc-1/2" (hot water) upvc (3/4" and 1" for cold water)
Drainage Pipe - Kissan/supreme or equivalent PVC (SWR-3" and 4") below plinth 6° for single line
Sanitary ware Cera kerovit or equivalent - 1. no. health faucet, 1 no. diverter 1 no. shower 1 no. w/c tap.1 wash basin (Master Bedroom toilet-40,000/-)
ISI, Cera kerovit or equivalent - 1. no. health faucet, 1 no. Mixer 1 no. shower 1 no. w/c tap.1 wash basin (Guest Bedroom -30,000/-)
Jaguar, Cera kerovit or equivalent - 1. no. health faucet, 1 no. Mixer 1 no. shower 1 no. w/c tap.1 wash basin (C Toilet - 20,000/-)
Kitchen Sink - Stainless steel grade 304 SS sink upto - 2200/-
OWHT - Supremo/Plasto or equivalent 1000 litre - 4 layer
UGWT - (4" brick, 4" rcc) 6000-7000 litre capacity
Chamber (Size 2'0" * 2'0") Chamber Cover: By kota stone

Internal Putty
Two coat-Birla white/Jk+ primer one coat
Colour
emulsion shine
External Front elevation
Apex Ultima 7 yrs warranty
Other side elevation
2 coat primer
Fabrication
Red Oxide Coating and Oil Paint

Window Grill - Bright bar (10mm/12mm) round/square bright bar
Main gate parking - Ms. iron upto 120 kg Ms door (cnc cutting and shera wood panels will be charged extra)
Railing - S.S./MS with Rs.600 per running ft upto ht of 3ft
Head room gate - M.S iron 18 gauge MS. sheet door, upto tili 40 kg
Tower ladder Ms pipe with ladder
